Variable Speed Drive harmonics solution for Drives causing or contributing to Motor failure. Sine wave creation of the output current on the output of a frequency drive.
Longer lifetime of motor insulation, noise reduction.

• Test voltage: L-L 1500 V, DC 1 s; L-PE 2500 V, DC 1s
• Overloadt: 1,5 x I rated 1 min / h
• Climatic Category: DIN IEC 60068-1
• Frequency: 0- 60 Hz
• Short circuit voltage Uk: 8% (with 400V)
• Voltage drop: 18,4 V/branch (with IN and 50Hz)
• Max. ambient temperature: 40°C
• Max. voltage ripple: 5%
• Clock frequency of converter: >= 4kHz
• Max. cable length to the motor: 600 m (shielded) / 1000 m (unshielded)
• Protection: IP20
