8A 1Q 115V/230V 1ph AC to DC Enclosed

Sprint 800ER - 8A Single Quadrant Reversing DC Thyristor Drive for 230 or 110V single phase AC input.
230V AC supply - 1.1kW (1.5HP) at 180V DC for motor speed and torque control.
110V AC supply - 0.55kW (0.75HP) at 90V DC.
Simple to set-up in analogue form.
Aluminium Enclosure: 175mm Wide x 100mm Deep x 250mm High.

Controls Include...
•On/Off AC supply rocker switch
•Set speed potentiometer
•AC supply fuse
•Toggle switch for forward, stop and reverse.

Features...
Fully fused
Zero speed interlocked reversing
Dynamic braking
